Molecular weight:192.96 g/mol
Theoretical content of combined-carbon: 6.224%
Density: 14.0-14.5g/cm3
Melting Point: 3875-4150 °C
Boiling Point: 5500 °C
Tantalum Carbide /TaC Powder
Tantalum Carbide is a refractory compound which has the appearance of dark brown or tawny powder, with the molecular weight of 192.86 g/mol, theoretical content of combined-carbon of 6.224%, density of 14-14.5 g/cm3, melting point of 3875-4150 °C, boiling point of 5500 °C. It does not dissolve in various acids (except the mixture of hydrofluoric acid and nitric acid). TaC powder has good chemical stability. It has a high oxidation resistance when heated to 1000 to 1100 °C in the air. Besides, it is widely used in carbide additives, also as molding and anti-oxidation coating material, as well as an important raw material in cermet material.
|
Tantalum Carbide/TaC Powders |
||||||||||||
|
Grade |
Chemical Composition (%) |
Average Particle size FSSS(μm) |
||||||||||
|
Total Carbon |
Free Carbon |
Impurity (max, %) |
||||||||||
|
Nb |
Fe |
Si |
Al |
Ti |
O |
N |
Na |
Ca |
||||
|
TaC-X |
6.2±0.2 |
≤0.15 |
0.10 |
0.05 |
0.01 |
0.005 |
0.01 |
0.50 |
0.20 |
0.005 |
0.01 |
0.6-0.8 |
|
TaC-1 |
6.2±0.2 |
≤0.15 |
0.10 |
0.05 |
0.01 |
0.005 |
0.01 |
0.35 |
0.20 |
0.005 |
0.01 |
0.8-1.2 |
|
TaC-2 |
6.2±0.2 |
≤0.15 |
0.30 |
0.05 |
0.01 |
0.005 |
0.01 |
0.20 |
0.20 |
0.005 |
0.01 |
1.2-1.5 |
|
TaC-3 |
6.2±0.2 |
≤0.15 |
0.30 |
0.05 |
0.01 |
0.005 |
0.01 |
0.15 |
0.20 |
0.005 |
0.01 |
1.5-2.0 |
*Chemical composition and particle size can be customized according to customer's requirement.
